VoxType OSD HUD for Omarchy Quattro

A floating, click-through voice HUD for VoxType that automatically matches your Omarchy theme, with a smooth animated reveal on every theme switch.

blizl.voxtype-osd is a clean-architecture Omarchy Quattro plugin providing a modern floating capsule HUD on-screen display (OSD), dynamic equalizer visualizer, live theme synchronization, engine switcher, and meeting controls for VoxType.

Features

• Modern Floating Capsule HUD: Sleek, glassy pill design matching the Omarchy Nord aesthetic with glassmorphic translucent backdrops (#2e3440 base with #88c0d0 Frost accents).
• Responsive Dynamic Equalizer: 16-bar audio equalizer driven by the live audio socket, with dBFS loudness mapping and fast-attack / slow-release ballistics so bars rise on each syllable and settle smoothly instead of twitching.
• Harmonic AI Wave Animation: Smooth traveling sine-wave visualizer active during AI transcription phases.
• Multi-State Feedback:
  • 🔴 Recording: Pulsing Nord scarlet indicator + live elapsed timer (0:14) + dynamic equalizer.
  • 🔵 Streaming: Nord Frost cyan glow with live voice activity.
  • 🟡 Transcribing: Nord amber glow + animated traveling wave.
  • 🟢 Voice Activity (VAD): Dynamic green halo trigger on active speech.
• Animated Theme Transitions: When the active Omarchy theme changes, the OSD plays a short masked reveal wipe — mirroring Omarchy's own wallpaper transition — instead of an abrupt colour flip, with a brief "peek" to confirm the change even while hidden. Reveal geometry is configurable (omarchy / grow / wipe-right / wipe-left / fade / none); see Theme transitions.
• Click-Through Wayland Overlay: Transparent WlrLayershell overlay with mouse event pass-through mask so the HUD never intercepts cursor clicks.
• Engine Picker Modal (SUPER + E): Floating popup (EnginePicker.qml) to switch between Whisper, Parakeet, Moonshine, SenseVoice, Paraformer, Dolphin, Omnilingual, and Cohere engines on the fly. Engines are split into what is ready to use versus what still needs downloading, so the list reflects your machine.
• Meeting Controls HUD (SUPER + M): Floating controls panel (MeetingControls.qml) surfacing active meeting title, duration, chunk count, and Start / Pause / Resume / Stop triggers.
• Atomic Rollback & Safety: Full transactional backups, automated checkpoints, and clean uninstaller restoring previous configurations without leaving orphaned files.

Engine Picker & Meeting Controls

The SUPER + E engine picker and SUPER + M meeting controls panel float over the desktop the same way the OSD does, and pick up theme changes live too.

The picker sizes itself from its contents, so the whole engine list fits on screen instead of clipping the last row, and it scrolls if a future engine would overflow. Each row carries a one-line capability blurb, and engines you have not downloaded stay visible under an Unavailable heading with the voxtype setup model command needed to fetch them.

Secondary text uses the theme's subtextColor, and selected and hover fills are tuned separately for light and dark themes so row text stays readable either way. Meeting controls get the same treatment.

Requirements

bin/setup checks for jq, voxtype and qs before touching anything. No files outside ~/.config/voxtype, ~/.local/share/voxtype, ~/.local/state/blizl.voxtype-osd and (only with your consent) ~/.config/hypr/bindings.lua are modified.

Installation

Via Omarchy Plugin Manager

omarchy plugin add https://github.com/Blizl/Omarchy-VoxType-OSD.git --enable \
  && ~/.config/omarchy/plugins/blizl.voxtype-osd/bin/setup

Direct / Local Setup

git clone https://github.com/Blizl/Omarchy-VoxType-OSD.git
cd Omarchy-VoxType-OSD
./bin/setup

Pass --yes or -y for non-interactive automated installations (e.g. scripts or CI):

./bin/setup --yes

Uninstallation & Recovery

Uninstalling

Via Omarchy Plugin Manager

Run the plugin's uninstaller first (it restores your previous VoxType config, removes the installed Quickshell files and the SUPER + E / SUPER + M bindings), then remove the plugin itself:

~/.config/omarchy/plugins/blizl.voxtype-osd/bin/uninstall \
  && omarchy plugin remove blizl.voxtype-osd

omarchy plugin remove on its own only deletes the plugin folder — it does not know about the files bin/setup created, so always run bin/uninstall first.

Direct / Local Setup

From the cloned repository:

./bin/uninstall

Both paths revert only what setup changed: the [osd] section of config.toml goes back to its pre-install content (any other edits you made since are kept), the installed Quickshell files and the keybinding block are removed. Re-running bin/setup (e.g. after an update) keeps the original pre-install baseline, so uninstalling later still returns you to where you started.

Recovery Utility

The included bin/restore utility allows rolling back configuration at any time:

# Revert to the pre-setup state:
./bin/restore --latest

# List available snapshot checkpoints:
./bin/restore --list

# Revert to a specific snapshot ID:
./bin/restore --checkpoint 20260816T230800Z-12345

# Reset to clean stock defaults (disabling OSD):
./bin/restore --stock

Configuration Reference

VoxType configuration is stored in ~/.config/voxtype/config.toml. The [osd] table governs HUD behavior:

[osd]
# Enable or disable the OSD overlay
enabled = true

# OSD frontend implementation ("quickshell", "egui", "cli", "none")
frontend = "quickshell"

# Placement on screen ("bottom-center", "top-center", "bottom-right", etc.)
position = "bottom-center"

# Pill dimensions (pixels)
width_px = 320
height_px = 48

# Distance from bottom screen edge (pixels)
margin_px = 80

# Backdrop glass opacity (0.0 - 1.0)
opacity = 0.96

# Visualizer gain for VoxType's other OSD frontends. The Quickshell HUD
# maps loudness in dBFS instead and doesn't read it (see Waveform below).
waveform_gain = 12.0

Theme transitions

When the active Omarchy theme changes, the OSD plays a short Omarchy-style masked reveal (matching the wallpaper switch animation) instead of an abrupt colour flip. This is controlled entirely by voxtype-shared/Theme.qml and picked up automatically by voxtype-shared/ThemeReveal.qml; no config file changes are needed, but it can be tuned or disabled via environment variables:

The reveal is automatically skipped (colours simply commit instantly) when transitionStyle is fade or none, or when the OSD surface isn't currently mapped/visible on screen.

Speaking indicator

While recording, the microphone glyph and its soft aura switch to the theme's green when you are speaking and back to the accent colour when you pause. That cue is debounced (voxtype-shared/VadGate.qml) rather than bound to the daemon's raw per-frame voice-activity flag, so it doesn't flicker on the short gaps between words: it only turns on after a short stretch of continuous voice, and only turns off after a longer stretch of continuous silence. The equalizer bars are not gated and keep reacting to every frame. The thresholds can be tuned via environment variables:

Blank or invalid values fall back to the defaults.

Waveform

The 16 equalizer bars are driven by voxtype-shared/WaveformMeter.qml. Each frame's peak is mapped through dBFS against a floor, so quiet speech still moves the bars and loud speech has headroom instead of pinning at the top, and every bar then eases toward its target with a fast attack and a slow release, so bars rise on a syllable and fall away gracefully rather than twitching with every frame. Sound scrolls across the strip from the left. The defaults live in voxtype-shared/Theme.qml:

Architecture & Codebase Structure

The plugin follows clean-architecture principles, separating pure logic libraries, executables, QML components, and tests:

Omarchy-VoxType-OSD/
├── manifest.json                  # Omarchy plugin manifest (schemaVersion 1, id: blizl.voxtype-osd)
├── LICENSE                        # MIT License
├── README.md                      # Documentation & guides
├── .gitignore                     # Git ignore rules
│
├── VoxTypeOsdOverlay.qml          # Omarchy shell plugin entrypoint
├── shell.qml                      # Quickshell standalone / VoxType entrypoint
├── OsdSurface.qml                 # Floating capsule HUD component
├── EnginePicker.qml               # Floating engine switcher modal
├── MeetingControls.qml            # Floating meeting controls HUD
│
├── voxtype-shared/
│   ├── qmldir                     # QML module definition & singletons
│   ├── Theme.qml                  # Adaptive theme singleton (Nord palette & geometry)
│   ├── ThemeReveal.qml            # Masked reveal transition overlay for theme changes
│   ├── StateReader.qml            # Reactive FileView state watcher ($XDG_RUNTIME_DIR/voxtype/state)
│   ├── AudioBridge.qml            # Sidecar NDJSON audio bridge process manager
│   ├── VadGate.qml                # Debounced speaking state for the mic glyph / aura
│   └── WaveformMeter.qml          # dBFS mapping + attack/release ballistics for the equalizer
│
├── bin/
│   ├── setup                      # Safe installer with confirmation, backups, and idempotency
│   ├── uninstall                  # Clean uninstaller with state restoration
│   └── restore                    # Snapshot checkpoint and stock recovery utility
│
├── lib/
│   ├── transaction.sh             # Atomic file rollback transaction manager
│   ├── checkpoint.sh              # Checkpoint snapshot, space check, and verification
│   ├── voxtype-config.sh          # TOML parser, modifier, and state inspector
│   ├── qml-installer.sh           # Safe QML component installer and verifier
│   ├── service.sh                 # Systemd user service lifecycle management
│   └── keybindings.sh             # SUPER+E / SUPER+M panel keybinding installer (conflict-aware)
│
└── tests/
    ├── run                        # Test runner script (executes all test suites)
    ├── helpers/
    │   └── test_helper.sh         # Isolated mock $HOME fixture generator & assertions
    ├── fixtures/
    │   └── sample_config.toml     # Sample TOML configuration for testing
    ├── config_test.sh             # Unit tests for TOML configuration engine
    ├── transaction_test.sh        # Unit tests for transaction rollback manager
    ├── qml_installer_test.sh      # Unit tests for QML file installer
    ├── checkpoint_test.sh         # Unit tests for snapshot checkpointing
    ├── service_test.sh            # Unit tests for service manager
    ├── setup_uninstall_test.sh    # E2E lifecycle and idempotency tests
    ├── restore_test.sh            # Recovery utility tests
    ├── keybindings_test.sh        # Keybinding install / conflict / uninstall tests
    ├── theme_switching_test.sh    # Live theme switching tests
    ├── theme_transition_test.sh   # Transition commit / de-dupe / env tests
    ├── vad_gate_test.sh           # Speaking-indicator debounce + env tests
    ├── waveform_meter_test.sh     # Equalizer loudness mapping + ballistics tests
    ├── qml_validation_test.sh     # QML lint + runtime load tests
    └── manifest_validation_test.sh# Manifest schema validation tests

Development & Verification

All scripts and libraries are strictly linted, formatted, and tested:

# Run unit and integration tests (100% pass rate):
./tests/run

# Shell script static analysis:
shellcheck bin/* lib/*.sh tests/*.sh tests/helpers/*.sh tests/run

# Shell script code formatting check:
shfmt -d -i 2 -ci bin/* lib/*.sh tests/*.sh tests/helpers/*.sh tests/run

# Validate plugin manifest with Omarchy CLI:
omarchy plugin validate .

Plugin Submission Checklist Compliance

License

Released under the MIT License. Copyright © 2026 Blizl Labs LLC.
